Accessories
Accessories
Mounting Brackets
Our high-quality brackets for precise mounting of your laser module offer fixed and multidirectional mounting capabilities. These brackets provide an easy, secure means of incorporating our lasers into any number of applications.
| Product Name | Description | Price | ||
|---|---|---|---|---|
 | MB3A-MAG2 | Multidirectional freely-rotating brass ball allows for 80° of angular freedom. The MB3a is suitable for modules 12.7mm (0.5 inch) in diameter, such as the PM – allows for mounting with magnets, -MAG2. | Contact Us | |
 | MB3C | Multidirectional freely-rotating brass ball allows for 80° of angular freedom. Secures modules 11mm (0.43 inch) in diameter, such as the RS. | Contact Us | |
 | MB10 | Mounting bracket for 1.50″ (38.1 mm) diameter laser modules. Ideal for IQ laser modules | Contact Us | |
 | MB9 | Adjustable Mounting Bracket for 1.0 inch (25.4mm) diameter laser modules | Contact Us | |
 | MB8 | Mounting bracket for 0.75″ (19.05 mm) diameter laser modules. Ideal for PNF and PMi lasers. | Contact Us | |
 | MB6 | Mounting bracket for 1.5″ (38 mm) diameter laser modules. Sold in pairs for optimal stability. | Contact Us | |
 | MB5 | Mounting bracket for 1.0″ (25.4 mm) diameter laser modules. | Contact Us | |
| MB3A | Mounting bracket with 80° conical rotation. The MB3a is suitable for modules 12.7mm (0.5 inch) in diameter, such as the PM. | Contact Us | |
 | MB2 | Fixed mounting bracket with split ring clamp. Compatible with 12.7 mm and 11 mm laser modules. | Contact Us | |
| MB3C-MAG2 | The MB3c secures modules 11mm (0.43 inch) in diameter, such as the RS – allows for mounting with magnets, -MAG2. | Contact Us | |
 | MB1c | Accommodates modules 11mm (0.433 Inch) in diameter. Ideal for use with RS modules. | Contact Us | |
| MB1a | Accommodates modules 12.7 mm (0.5 Inch) in diameter. Ideal for use with PM modules. | Contact Us |
Power Distribution Units (PDU)
Power multiple laser modules from a single point DC source with our Power Distribution Units (PDU).
With three models to choose from, the PDU offer cost-effective and convenient power splitting solutions to multiple laser modules. They are designed to eliminate the need for an individual power supply for each laser and AC power strips.
Laser Diode Control Units (LDCU)
The Laser Diode Control Unit (LDCU) is a CE-compliant turnkey power source that contains U.S. government-mandated safety features. The LDCU enables us to offer original equipment manufacturer (OEM) laser products as complete laser systems.
The LDCU incorporates the following safety features to comply with government regulations for class 3B (or below) laser systems: a power on/off key switch, emission indicator, beam blocker, and remote interlock and connector. Class 4 LDCU systems also include these safety features, in addition to a manual 5-second activation delay on the front panel.
We offer several versions of the LDCU, each accommodating laser modules with one of the following output voltages: 3.3, 5, 8, and 12VDC. Input voltages of 120 and 220VAC are available. A DB-9 (9-pin) connector is located on the rear panel of the LDCU. A bare wire adapter is available should your laser module not have a DB-9 connector installed.
| Product Name | Description | Price | ||
|---|---|---|---|---|
 | LDCU8-HC | 8V DC power source for Laser Modules. Compliant with CDRH regulations for ‘End Users’. 120VAC input | $534.60 | |
| LDCU5-HC | 5V DC power source for Laser Modules. Compliant with CDRH regulations for ‘End Users’. 120VAC input | $534.60 | |
| LDCU5-220 | 5V DC power source for Laser Modules. Compliant with CDRH regulations for ‘End Users’. 100-220VAC input | $445.02 | |
| LDCU8-220 | 8V DC power source for Laser Modules. Compliant with CDRH regulations for ‘End Users’. 100-220VAC input | $445.02 | |
| LDCU5-120 | 5V DC power source for Laser Modules. Compliant with CDRH regulations for ‘End Users’. 120VAC input | $263.97 | |
| LDCU8-120 | 8V DC power source for Laser Modules. Compliant with CDRH regulations for ‘End Users’. 120VAC input | $263.97 | |
| LDCU-ACS-BWA | Bare wire adapter for laser modules without a DB-9 connector installed. | $48.60 |
Optomechanical Components
Our optomechanical components are precision-engineered to enhance optical alignment, thermal stability, and the safe handling of delicate optics.
Featuring the innovative Adjust-A-Ball® mechanism, these components ensure even distribution of the coefficient of thermal expansion (CTE) around the mirror’s center of mass, minimizing the effects of temperature fluctuations on alignment. Fine-adjust mirror mounts allow precise control with three adjustment screws, accommodating Ø1/2” mirrors with optional epoxy pockets for permanent placement.
The OPTIC-GRAB® tweezers, available in multiple sizes, offer a revolutionary, scratch-free way to handle fragile optics using RoHS-compliant, static-dissipative polymers with patented transfer capabilities. These versatile, user-friendly components are designed for both novice and experienced optical scientists, ensuring seamless integration into demanding optical systems.
| Product Name | Summary | Price | ||
|---|---|---|---|---|
 | FAP5 Fine Adjust Post Mount, 1/2″ Optic | Post-mountable with ±7° adjustability and >0.88 µm resolution, this mount secures Ø1/2” optics with a retaining ring and allows precise x-y alignment via three screws. (Post and lock nuts sold separately.) Black or Silver Finish. | $195.00 | |
 | FAB5 (Silver) AB1 Series Fine-Adjust 1/2″ | This precision mount offers ±7° adjustability and >0.88 µm resolution per turn, securing Ø1/2” mirrors with a retaining ring or epoxy. Compatible with Adjust-A-Ball® (sold separately), it ensures stable alignment during temperature changes with quick x-y adjustments via three precision screws. Silver Finish. | $195.00 | |
 | FAB5 (Black) AB1 Series Fine-Adjust 1/2″ | This precision mount offers ±7° adjustability and >0.88 µm resolution per turn, securing Ø1/2” mirrors with a retaining ring or epoxy. Compatible with Adjust-A-Ball® (sold separately), it ensures stable alignment during temperature changes with quick x-y adjustments via three precision screws. Black Finish. | $195.00 | |
 | AB5 (Silver): Adjust-A-Ball for 1/2″ Mirrors | Designed for the precise alignment of 1/2″ mirrors, the AB5 Adjust-A-Ball® ensures even CTE distribution, maintaining stability during temperature changes. Its smooth, multiaxial movement and tool-free locking mechanism provide effortless adjustments without compromising alignment. Silver Finish. | $195.00 | |
 | AB5 (Black): Adjust-A-Ball for 1/2″ Mirrors | Designed for the precise alignment of 1/2″ mirrors, the AB5 Adjust-A-Ball® ensures even CTE distribution, maintaining stability during temperature changes. Its smooth, multiaxial movement and tool-free locking mechanism provide effortless adjustments without compromising alignment. Black Finish. | $195.00 | |
 | AB1 (Silver): Adjust-A-Ball for 1″ Mirrors | Designed for 1” mirrors, the Adjust-A-Ball® mount ensures even CTE distribution to maintain stable optical alignment, unaffected by temperature fluctuations, with a smooth, tool-free locking mechanism. Silver finish. | $195.00 | |
 | AB1 (Black): Adjust-A-Ball for 1″ Mirrors | Designed for 1” mirrors, the Adjust-A-Ball® mount ensures even CTE distribution to maintain stable optical alignment, unaffected by temperature fluctuations, with a smooth, tool-free locking mechanism. Black finish. | $195.00 | |
 | OPTIC GRAB – Optics Handling Tongs – Bundle | Get the best of both sizes with this bundle. This bundle includes one (1) OG1 and one (1) OG5 of the same color. | $13.99 | |
 | OG1: OPTIC GRAB for 25.4 mm Optics | Effortless, scratch-free handling for 1” (25.4mm) optics, with static-dissipative, chemical-resistant polymers and hands-free operation. Perfect for transferring and cleaning lenses without direct contact. | $13.99 | |
 | OG5: OPTIC GRAB for 12.7 mm Optics | Effortless, scratch-free handling for 0.5” (12.7mm) optics, with static-dissipative, chemical-resistant polymers and hands-free operation. Perfect for transferring and cleaning lenses without direct contact. | $13.99 |
