Pulsed Diode Laser Modules – ILC Series
Delivering high power pulses in a compact form factor for defense, industrial, scientific and biomedicine research and OEMs

Browse Configured Modules:

Model NameWavelength (nm)Peak Pulse Power (W)Pulse Width (ns)Pulse Rise Time (ns)Pulse Fall Time (ns)More Details ↓hf:att:pa_wavelength-nmhf:att:pa_power
Pulsed Diode Laser Modules (ILC Series) - 1550, 60, W, 1   40, 0°C - 80°C, 4 300

ILC(1550-60)

1550604-3001 – 401 – 20155060
Pulsed Diode Laser Modules (ILC Series) - 1550, 5, W, 1   40, 0°C - 80°C, 4 300

ILC(1550-5)

155054-3001 – 401 – 2015505
Pulsed Diode Laser Modules (ILC Series) - 905, 150, W, 1   40, 0°C - 50°C, 4 300

ILC(905-150)

9051504-3001 – 401 – 20905150
Pulsed Diode Laser Modules (ILC Series) - 905, 4, W, 1   40, 0°C - 80°C, 4 300

ILC(905-4)

90544-3001 – 401 – 209054
Pulsed Diode Laser Modules (ILC Series) - 1064, 1, W, 1   40, 0°C - 50°C, 4 300

ILC(1064-1)

106414-3001 – 401 – 2010641
Pulsed Diode Laser Modules (ILC Series) - 850, 100, W, 1   40, 0°C - 80°C, 4 300

ILC(850-100)

8501004-3001 – 401 – 20850100
Pulsed Diode Laser Modules (ILC Series) - 850, 4, W, 1   10, 0°C - 80°C, 4 300

ILC(850-4)

85044-3001 – 101 – 208504
Pulsed Diode Laser Modules (ILC Series) - 670, 10, W, 1   40, 0°C - 60°C, 4 300

ILC(670-10)

670104-3001 – 401 – 2067010
Pulsed Diode Laser Modules (ILC Series) - 638, 1.5, W, 1   40, 0°C - 50°C, 4 300

ILC(638-1.5)

6381.54-3001 – 401 – 206381-5
Pulsed Diode Laser Modules (ILC Series) - 465, 20, W, 1   40, 0°C - 50°C, 8 300

ILC(465-20)

465208-3001 – 401 – 2046520

Looking for something a little more custom? We completely understand.

We understand that certain precision applications—such as advanced manufacturing, biomedical imaging, or defense systems—demand exact tolerances and unique specifications. That’s why we provide customization options, including wavelength selection, pulse width adjustment, output power optimization, and specialized beam shaping. Whether you need a tailored solution for harsh environments or integration into compact systems, our engineering team is ready to collaborate with you to meet your exact requirements. Reach out to The Laser Experts today!

ILC Pulsed Laser, Pictured Above: Available in either 25.4mm or 31.75mm module sizes

ILC LASER IN ACTION:

Vinokhodov, A., Krivokorytov, M., Sidelnikov, Y., Krivtsun, V., Medvedev, V., Bushuev, V., Koshelev, K., Glushkov, D., & Ellwi, S. (2016). Stable droplet generator for a high brightness laser produced plasma extreme ultraviolet source. Review of Scientific Instruments, 87(10), 103304. https://doi.org/10.1063/1.4964891

ILC Pulser in Stroboscopic Backlight Imaging:

In the paper titled “Stable Droplet Generator for a High Brightness Laser Produced Plasma Extreme Ultraviolet (EUV) Source” (Vinokhodov et al., 2016), the IL30C pulsed laser served as a stroboscopic backlight to illuminate and capture high-speed images of liquid metal droplets in flight. By emitting short, intense pulses, the IL30C “freezes” the droplet’s motion at precise intervals—enabling accurate measurement of droplet size, velocity, and positioning. This stroboscopic method was crucial for synchronizing the droplets as targets for laser-produced plasma, ultimately enhancing the stability and brightness of the EUV source.
Galanzha, E. I., Shashkov, E. V., Spring, P., Suen, J. Y., & Zharov, V. P. (2009). In vivo, noninvasive, label-free detection and eradication of circulating metastatic melanoma cells using two-color photoacoustic flow cytometry with a diode laser. Cancer Research, 69(20), 7926–7934. https://doi.org/10.1158/0008-5472.CAN-08-4900

ILC Pulser In Vivo Detection and Eradication of Metastatic Melanoma Cells:

In the study titled “In Vivo, Noninvasive, Label-Free Detection and Eradication of Circulating Metastatic Melanoma Cells Using Two-Color Photoacoustic Flow Cytometry with a Diode Laser”, published in Cancer Research (Galanzha et al., 2009), the ILC Pulsed Laser was instrumental in developing a novel method for noninvasive cancer diagnostics. This method achieved high-sensitivity detection and eradication of metastatic melanoma cells in vivo, demonstrating the laser’s exceptional performance in biomedical applications.
